- Stylus Systems
Stylus systems are the basis for accurate measurements. We offer a variety of components for building your individual stylus system.
Connection Type
Measuring System
Product Type
Ø Body (DG)
Ø Sphere (DK)
Length (L)
Material
Stylus Tip Material
Shaft Material
Stylus Type
Stylus Tip
Meas. Len.
Meas. Len. (MLE)
Ø Shaft (DS)
Ø Shaft2 (DSE)
Connection Type Out
Stylus with thread, M5, straight
626105-0824-077
- Ø Sphere (DK)
- 8,0 mm
- Length (L)
- 77,0 mm
- Measuring Length (ML)
- 64,0 mm
- Ø Shaft (DS)
- 6,0 mm
- Stylus Tip Material
- Ruby
- Shaft Material
- Tung. Carb
102,00 €Sales tax not included
Delivery time: 2 days
Stylus with thread, M5, straight
626105-1024-147
- Ø Sphere (DK)
- 10,0 mm
- Length (L)
- 147,0 mm
- Measuring Length (ML)
- 134,0 mm
- Ø Shaft (DS)
- 6,0 mm
- Stylus Tip Material
- Ruby
- Shaft Material
- Tung. Carb
120,00 €Sales tax not included
Delivery time: 2 days
Star stylus with cube, M5, stepped
626115-5000-177
- Ø Sphere (DK)
- 1,0 mm
- Length (L)
- 25,0 mm
- Measuring Length (ML)
- 6,5 mm
- Ø Shaft (DS)
- 4,0 mm
- 2. Measuring Length (MLE)
- 2,5 mm
- Ø 2. Shaft (DSE)
- 0,8 mm
- Stylus Tip Material
- Ruby
- Shaft Material
- Tung. Carb
532,00 €Sales tax not included
Delivery time: 2 days
Stylus with thread, M5, straight
626105-0514-165
- Ø Sphere (DK)
- 5,0 mm
- Length (L)
- 165,0 mm
- Measuring Length (ML)
- 155,0 mm
- Ø Shaft (DS)
- 3,5 mm
- Stylus Tip Material
- Ruby
- Shaft Material
- Tung. Carb
138,00 €Sales tax not included
Delivery time: 2 days
Angle block short, ThermoFit Pro system
626107-6021-046
- Length (L)
- 25,0 mm
- Measuring Length (ML)
- 17,0 mm
- 1. Angel (W1)
- 90 °
114,00 €Sales tax not included
Delivery time: 2 days
Stylus with thread, M5, straight
626105-0824-109
- Ø Sphere (DK)
- 8,0 mm
- Length (L)
- 109,0 mm
- Measuring Length (ML)
- 96,0 mm
- Ø Shaft (DS)
- 6,0 mm
- Stylus Tip Material
- Ruby
- Shaft Material
- Tung. Carb
102,00 €Sales tax not included
Delivery time: 2 days
587,00 €Sales tax not included
Delivery time: 2 days
Stylus with thread, M5, straight
626105-0515-156
- Ø Sphere (DK)
- 5,0 mm
- Length (L)
- 156,0 mm
- Measuring Length (ML)
- 146,0 mm
- Ø Shaft (DS)
- 3,5 mm
- Stylus Tip Material
- Si-N
- Shaft Material
- Tung. Carb
62,00 €Sales tax not included
Delivery time: 2 days
Stylus with thread, M5, straight
626105-1024-130
- Ø Sphere (DK)
- 10,0 mm
- Length (L)
- 130,0 mm
- Measuring Length (ML)
- 117,0 mm
- Ø Shaft (DS)
- 6,0 mm
- Stylus Tip Material
- Ruby
- Shaft Material
- Tung. Carb
120,00 €Sales tax not included
Delivery time: 2 days
Stylus with thread, M5, straight
626105-0474-146
- Ø Sphere (DK)
- 4,0 mm
- Length (L)
- 146,0 mm
- Measuring Length (ML)
- 136,0 mm
- Ø Shaft (DS)
- 3,0 mm
- Stylus Tip Material
- Ruby
- Shaft Material
- Tung. Carb
72,00 €Sales tax not included
Delivery time: 2 days
