Workpiece Fixturing

Whether for tactile, optical or X-ray applications: Fixing the component on the measuring device is decisive in order to achieve meaningful and accurate measuring results. ZEISS clamping devices and accessories are designed to be universal: They are suitable for a wide variety of geometries and measuring devices. You can choose from well thought-out kits, the components of which can also be purchased separately, as well as universal clamping devices such as vices and three-jaw chucks.
Read more about Workpiece Fixturing
OmniFix Vise, 80 x 120
626109-9220-210
1.235,00 €Sales tax not included
 Express: Shipment today
 Delivery information
OmniFix Vise, 170 x 420
626109-9220-280
1.485,00 €Sales tax not included
 Express: Shipment today
 Delivery information
Part Fastening D20 M6 - Flat Magnet
600062-0001-245
18,00 €Sales tax not included
 Shipment within: 1 day
Jaw chuck pallet DuraMax
626109-9210-040
445,00 €Sales tax not included
 Express: Shipment today
 Delivery information
OmniFix® Kit lite – M6, 240x240mm
600062-0351-022
890,00 €Sales tax not included
 Shipment within: 2 days
Plastic clamping system for O-INSPECT
626109-9511-100
645,00 €Sales tax not included
 Shipment within: 2 days
OmniFix Vise, 170 x 320
626109-9220-270
1.475,00 €Sales tax not included
 Shipment within: 2 days
Rotary bench vise for SFG
626108-9010-000
1.550,00 €Sales tax not included
 Shipment within: 3 days
Styrofoam block, 15° B120
626140-9311-120
79,00 €Sales tax not included
 Shipment within: 6 days
THETA 32 Set grid M6 with chuck
626109-9220-140
1.899,00 €Sales tax not included
 Shipment within: 6 days
161 Items
Clamp or hold?

Clamp or hold?

Clamp or hold: These are the variants used to position components for measurement. Frictional clamping devices are used when probing forces are applied in tactile metrology or machine movements can influence the position of the workpiece (e.g. active damping). In optical metrology or CT applications the body is held, i.e. brought into a defined position, without exerting force. This corresponds to the VDI guideline 2860, among others.
Statically determined

Statically determined

In all cases, the aim is to achieve static determinacy: For non-deformable workpieces, static under-determinacy is avoided by defining them in all six degrees of freedom - translatory in three directions and rotary around three axes. For deformable workpieces, such as objects made of sheet metal or plastic that deform before assembly, static overdeterminacy must be avoided.
